1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface

1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface

  • 1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface
  • 1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface
  • 1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface
  • 1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface
1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface
Product Details:
Place of Origin: china
Brand Name: BOE
Certification: RoHS
Model Number: YT010BT001
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: USD 1.81-2.5/ PCS
Packaging Details: 50cm*50cm*60cm
Delivery Time: 20-25
Supply Ability: 1kk/m
Contact Now
Detailed Product Description
Size: 1.0 Inch Display Mode: Normally White
Resolution: 128*96 Active Area: 20.352( W) × 15.264(L)
Viewing Angle: 12 O'clock Brightness: 200 Cd/m2
Colors: 262K Interface: 4-SPI
High Light:

128X64 TFT LCD Touch Screen

,

128X64 1 inch tft display

,

SPI Interface 1 inch tft display

1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface



       YT010BT001  is a color active matrix thin film transistor (TFT) liquid crystal display without polarizer. This model is composed of amorphous silicon TFT as a switching device. It is a transmissive type display operating in the normally white mode.

       This TFT LCD has a 1.0-inch diagonally measured active display area with 128 x 96 dot (128 vertical by 96 horizontal pixel) resolution. Each pixel is divided into Red, Green, Blue dots which are arranged in vertical stripes.



Features


1.0.4T Glass
2.Thin and light weight
3.Low Power consumption, High trans, High CR, Wide view angle
4.RoHS Compliant



Application

Adiadisplay modules had been widely used in all kinds of industries,like smart watch,smart bracelet,smart home,smart robots,smart furniture, car system, cummunication devices, tablet,POS devices,medical equipments, education devices, bike DVR,3D printer, industrial controller, security equipment,digital greeting card, recreation equipment etc…




General Specifications



NO. Item Specification Unit Remark
1 LCD Size 1.0 inch -
2 Panel Type TN - -
3 Resolution 128x (RGB) x 96 pixel -
4 Display Mode Normally white,Transmissive - -
5 Display Number of Colors 262k - Note
6 Viewing Direction 12 o'clock - -
7 Contrast Ratio 200(min) - -
8 Luminance 200(TYP) cd/m2 Note
9 Module Size 23.75(W) ×22.06( L) ×1.75(T) mm Note
10 Active Area 20.352( W) × 15.264(L) mm -
11 Pixel Pitch 0.159(W ) x 0.159(L) mm -
12 Weight - g -
13 Driver IC ST7735S - -
14 CTP Driver IC GT1911 bit -
15 CTP Interface II2C
16 Light Source 2LEDs White - -
17 Interface SPI - -
18 Operating Temperature -20~70 ºC -
19 Storage Temperature -30~80 ºC -



Outline Dimension (unit: mm)



1.0 Inch 128X64 TFT LCD Touch Screen With SPI Interface 0



Related Products



Size Model No. Resolution Outline dimension
(LCM) H*V*T(mm)
Interface View direction
0.96 YT096H001 80*160 13.30*27.95* 1.38 SPI All O'Clock
1.44 YT144C001-V7 128*128 32.30*38.00*2.70 MCU 12 O'Clock
1.44 YT144C001-V13 128*128 32.30*38.00*2.70 MCU 12 O'Clock
1.77 YT177H040-V1 128*160 34.00*47.00*2.45 MCU 12 O'Clock
2.0 YT020H263 176*220 41.50*49.10*2.45 MCU 12 O'Clock
2.0 YT020M263 176*220 41.50*49.10*2.45 MCU 12 O'Clock
2.0 YT020M264 176*220 41.50*49.10*2.20 MCU 12 O'Clock
2.4 YT024C017 240*320 42.72*60.26*2.25 SPI+RGB/MCU ALL
2.8 YT028H003 240*320 50.00*69.20*2.40 MCU ALL
2.8 YT028I001 240*320 50.00*69.20*2.40 MCU 12 O'Clock
3.5 YT035F001 320*480 54.66*82.94*2.20 MIPI 12 O'Clock
3.5 YT035C025 320*480 55.00*84.71*2.25 MCU/SPI ALL
3.5 YT043H007 480*800 62.46*105.9*2.20 SPI+RGB ALL
4 YT043H012 480*800 62.46*105.9*2.20 MIPI 12 O'Clock
4.3 YT445H006 480*854 60.04*109.42*1.95 RGB ALL
4.5 YT045I001 480*854 60.00*109.00*1.85 MIPI ALL
5 YT050B008 720*1280 64.70*118.70*1.55 MIPI ALL
5 YT050C001 1080*1920 64.9*119.75*2.2 RGB ALL
5 YT055H005-V1 480*800 70.34*128.11*2.05 RGB ALL
5.5 YT055B001 1080*1920 71.00*129.56*1.50 MIPI ALL





Why Choose us:



1.Our company established in 2011, and have a long-term cooperation with many well-known company

2.We have a professional r&d team and technical support

3.We have a large number of spot inventory and we can ship delivery asap after payment

4.We are direct agent of these brands,ordering process simple and delivery time short

5.All screen ship from our company has long warranty and we have enough technical support can provide

after-sales service



FAQ

1. How to understand Stock for Sale.


Answer:According to the company regulation, each standard product must be kept the stock of 1000pcs.

When the stock is less than 1000 pcs, we will put it into production at once instead of waiting for the orders. When the stock are more than 5000 pcs, the production must be stopped.

Appropriate stock is a very good support for the customer’s sampling and trial production demand.

The appropriate stock is also a guarantee of the quality. The production of the stock is always having more time than the production of the order. We have enough time to do more checking and to consider all the possible factors affecting the quality,
what’s more, in case that our products has been found a problem at the customer’s production, we have the stocked ones to do the replacement.

The appropriate stock is also a good way to reduce the cost. In busy seasons, we can produce the orders, while in free seasons, we can produce the stock. By this way, the labor source is maximumly used. At the same time, in free season, the materials can be bought at lower price.

2. How does Adia do for Never End of Supply?

Answer:EOL(End of Life) is largely because of end of life of the raw materials

When the EOL of the raw materials such as drivers and LCD panels happens, we can place a very large order with the supplier which may cover the consumption of one or two year. This large order is enough for the supplier to restart the production.

On the other hand, we can develop the replacement product which is mechanically and functionally the same as the previous one. For
the customer, only software will be changed a little while the hardware will remain the same.



Adia has built comprehensive relationships with the supplier samsun as LG, Hannstar and BOE and we can get the EOL products through our special channel to guarantee the continuous supply.

In LCD industry, due to the quick update of the technology, never end of supply is hard, but so far, Adia has never disappointed any customer.

Once the customer chooses us, we will offer the unchanged service till the end. Long-time relationship and mutual trust are our target and we hate well beginning but bad ending.

3. How to understand No MOQ?

Answer:The quantity of the order is decided by the market. As a supplier, we have no right to request the order must be more than any quantity. We have no MOQ request, a single piece is also a good order for us.

In another way, our products are always having stock, we don’t need to start the production for a small quantity, and we are capable enough of accepting the small orders.

However, if the quantity is small, the price will be higher.

4. How to understand in Full Range.
Answer:In full range means that our products are in great variety. We have what other manufacturers have, and we have what they don’t have. The customer is easy to find what they want in our product group. Like Walmart instead of Seven Eleven, all kinds of the products are placed before us and it is easy to attract the customers to come, so we like going shopping in Walmart, but we don’t like to go to Seven Eleven.





5. How does Adia guarantee the quality?

Answer: Adia has passed ISO9001:2008 certification. ISO principle is carried out in daily activities. The quality is strictly controlled in designing, material incoming, production process, equipment, management and checking and the rejects are not allowed to flow at any circumstances.

Adia has thousands of customers, in many cases, one product is being used by many customers. If one product is used by many factories, the quality is believable because most of the problems were solved already.

The Adia is following the quality standards from automotive industry. Special attention is paid to the capacity of anti-high-temperature, anti-shock and aftersales reliability. We don’t fear the rejects on the production line, we badly fear the rejects at the final consumer’s hand. Solving such kind of rejects are most costly. Adia is always pursuing 0 aftersales reject, so we adopted the strictest quality standards.

6. Why are Adia’s products higher in price?

Answer: The LCD quality has three standards: 1.consuming standards.2.Industrial standards 3.Automotive standards. Automotive standards are the highest grade which require the strong anti-shock capacity, anti-high-temperature capacity, high reliability and very low rate of reject. To follow automotive standards, we have to select the best raw materials, and bring in the most expensive equipment and very tough management, so our cost is higher.

In fact, our higher price is only manifested in samples. If the quantity is higher or the cooperation time is long, as long as the customer files the price request, the favorable price can be available after negotiation.

7. How long can we expect the samples?

Answer: Immediately in most of the cases.



PRECAUTIONS



1.HANDLING



1.1.Polarizer Cleaning, Petroleum ether (or N-hexane) is recommended for cleaning the front/rear polarizers and reflectors, acetone, toluene and ethanol are not allowed to avoid damaging the surface.

1.2. Body grounding, must wear Anti-ESD wrist strap while pick up LCDs.

1.3. FPC Soldering, less than 300℃/3S, solder must be grounding on grounding bench.

1.4. If use electric Screwdriver to do assembly, screwdriver must be grounding.



2.STORAGE



2.1. Keep in a sealed polyethylene bag.

2.2. Keep in a dark place.

2.3. Keep in temperature between 0°C and 35°C.

NOT allowed at 70°C for more than 160 Hours, or at -20°C for more than 48 Hrs.



3.SAFETY



If liquid crystal leak out of a damaged glass cell, DO NOT put it in your mouth or touch eyes, if the liquid crystal touch your skin or clothes, please wash it off immediately using soap and water.



4.LIMITED WARRANTY



Unless otherwise agreed between ADIA and customer, ADIA will replace or repair any of its LCD modules which are found to be functionally defective when inspected in accordance with ADIA LCD acceptance standards (copies available upon request) for a period of one year from date of shipments. Cosmetic/visual defects over specs must be returned to ADIA within 30 days of shipment. Confirmation of such date shall be based on freight documents. The warranty liability of ADIA limited to repair and/or replacement on the terms set forth above. ADIA shall not be responsible for any subsequent or consequential events.



4.1RETURNING LCM UNDER WARRANTY – TERMS AND CONDITIONS



4.1.No warranty can be granted if the precautions stated above have been disregarded. The typical examples of violations are :

- Broken LCD glass.

- Circuit modified in any way, including addition of components.

4.2.Module repairs will be invoiced to the customer upon mutual agreement. Modules must be returned with sufficient description of the failures or defects. Any connectors or cable installed by the customer must be removed completely without damaging the PCB’s eyelet, conductors and terminals.
