188PPI 1.28" TFT Color Touch Screen 240X240 Watch NTSC Round LCD Display

Product Details

Place of Origin: china

Brand Name: HSD

Certification: RoHS

Model Number: YT0128H005

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Price: USD 7.1-7.5/ PCS

Packaging Details: 50cm*50cm*60cm

Delivery Time: 20-25

Supply Ability: 1kk/m

Get Best Price
Contact Now
Specifications
Highlight:

1.28" TFT Color Touch Screen

,

188PPI TFT Color Touch Screen

,

240X240 NTSC Round LCD Display

Size:
1.28 Inch
Type:
A-Si TFT-LCD, CELL
Resolution:
240(RGB)×240 188PPI
Active Area:
23.40( W) × 23.40(L)
Viewing Angle:
Symmetry
Transmittance:
4.9% (Typ.)(with Polarizer)
Support Color:
262K 60% NTSC
Response Time:
30 (Typ.)(Tr+Td)
Operating Mode:
IPS Pro, Normally Black, Transmissive
Configuration:
RGB Vertical Stripe
Size:
1.28 Inch
Type:
A-Si TFT-LCD, CELL
Resolution:
240(RGB)×240 188PPI
Active Area:
23.40( W) × 23.40(L)
Viewing Angle:
Symmetry
Transmittance:
4.9% (Typ.)(with Polarizer)
Support Color:
262K 60% NTSC
Response Time:
30 (Typ.)(Tr+Td)
Operating Mode:
IPS Pro, Normally Black, Transmissive
Configuration:
RGB Vertical Stripe
Description
188PPI 1.28" TFT Color Touch Screen 240X240 Watch NTSC Round LCD Display

1.28 inch TFT color screen 1.3 inch round LCD display 240X240 watch industrial screen



      The  YT013H005  is a 1.28 inch diagonal a-Si TFT-LCD display panel product from HannStar Display Corporation (hereafter called HannStar), without backlight, without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are summarized by ADIA in the following: Circular Display , 1/4 Cut. Based on its features, Panelook recommend that this model be applied to Wearable, Round Display etc.





Features


1.0.25t Glass
2.Thin and light weight
3.Low Power consumption, High trans, High CR, Wide view angle
4.RoHS Compliant



General Specifications

NO. Item Specification Unit Remark
1 LCD Size 1.28 inch -
2 Panel Type a-Si TFT-LCD, LCM - -
3 Resolution 240(RGB)×240 188PPI pixel -
4 Display Mode IPS Pro, Normally Black, Transmissive - -
5 Display Number of Colors 262K/16.7M - Note
6 Viewing Direction ALL - -
7 Contrast Ratio 1100(min) - -
8 Luminance 300(TYP) cd/m2 Note
9 Module Size 35.60(W) ×38.10( L) ×1.50(T) mm Note
10 Active Area 32.40( W) × 32.40(L) mm -
11 Pixel Pitch 0.135(W ) x 0.135(L) mm -
12 Weight TBD g -
13 Driver IC ST7789V - -
14 Driver IC RAM Size RAMLess bit -
15 Light Source 2LEDs White - -
16 Interface SPI - -
17 Operating Temperature -20~70 ºC -
18 Storage Temperature -30~80 ºC -



188PPI 1.28" TFT Color Touch Screen 240X240 Watch NTSC Round LCD Display 0

Related Products

Size Model No. Resolution Outline dimension
(LCM) H*V*T(mm)
Interface View direction
2.31 YT023H003 320*240 50.80*45.80*2.46 MCU/SPI 12 O'Clock
2.4 YT024H001 240*320 42.72*60.26*2.25 MCU 12 O'Clock
2.4 YT024C017 240*320 42.72*60.26*2.25 SPI+RGB/MCU ALL
2.8 YT028H003 240*320 50.00*69.20*2.40 MCU ALL
2.8 YT028I001 240*320 50.00*69.20*2.40 MCU 12 O'Clock
3.5 YT035F001 320*480 54.66*82.94*2.20 MIPI 12 O'Clock
3.5 YT035C025 320*480 55.00*84.71*2.25 MCU/SPI ALL



Why Choose us:

1.Our company established in 2011, and have a long-term cooperation with many well-known company.

2.We have a professional r&d team and technical support.

3.We have a large number of spot inventory and we can ship delivery asap after payment.

4.We are direct agent of these brands,ordering process simple and delivery time short.





FAQ

Q1. How can I trust your product quality?

A:

--Our Raw materials are all ROHS compliant .

--Display is an ISO9001:2008 and ISO9001:2015 Certified company, we’ve been adhering to the ISO standards strictly in our production.

--Our products are 100% Visual and Function test before shipments.

Meanwhile, we do necessary Aging test and Reliability tests to our TFT Display modules, eg. Store and Operate in High and Low Temperature & High Humidity Environment, ESD and anti-interference test , Drop(with package) and Vibration Test.

Our Touch Screens goes through Salt spray test, Hardness test, Steel ball Drop test, Flatness test, Thermal shock test…

--Our experience and proficiency make the qualification rate always being 99.7% or above.



Q2. Which sizes of LCDs and Touch Panels do you provide?

A:

--Small sizes which include: 0.96, 1.22, 1.3, 1.44, 1.54, 1.77, 2.0, 2.4, 2.7, 2.8, 3.0, 3.2, 3.5, 3.95, 3.97, 4.3, 5, 5.6, 6.86.

--Middle sizes which include: 7, 8, 9, 10.1, 10.2, 13.3”,14.1",15.6",17",21.5",23



Q3. Can I have a sample order of before formal order?
A: Yes, sample order is always welcome for new projects or replacement of running projects. We have stock of many standard models of TFT LCD modules and Touch screens from 0.96inch to 13.3inch , which means delivery is able to be made the same day as order.



Q4. What is the lead time for Sample order and Mass Production order?
A:
--For LXDisplay standard products, the lead time for samples is usually 1-7 days, for mass production it could be as fast as 10 days.

--For Customized products,

We are able to get new FPC ready in 7days, new Backlight in 15days, and new Capacitive touch panel or Resistive touch panel in 18days.

Mass production of special products could be as fast as 3weeks.

--In summary, based on our years of big output, we have been keeping good relationship with LCD panel, IC and other material suppliers, we had a steady supply even when there was heavy shortage of materials.



Q5. Do you have MOQ requirement?
A: Yes, it depends on different sizes of products. Please refer to our sales, thanks.



Q6. How do I work with you on Customized products?
A: Firstly please provide us the description of your special requirements, any Drawing or Specification---Our engineers will work out the compatible solution and also mould cost (if any)---We provide Drawing and Specification for Approval---We provide samples for approval after reliability test and aging test---We make modification if necessary---We do small quantity of trial order (if required)---We do mass production.







PRECAUTIONS



1.HANDLING



1.1.Polarizer Cleaning, Petroleum ether (or N-hexane) is recommended for cleaning the front/rear polarizers and reflectors, acetone, toluene and ethanol are not allowed to avoid damaging the surface.

1.2. Body grounding, must wear Anti-ESD wrist strap while pick up LCDs.

1.3. FPC Soldering, less than 300℃/3S, solder must be grounding on grounding bench.

1.4. If use electric Screwdriver to do assembly, screwdriver must be grounding.



2.STORAGE



2.1. Keep in a sealed polyethylene bag.

2.2. Keep in a dark place.

2.3. Keep in temperature between 0°C and 35°C.

NOT allowed at 70°C for more than 160 Hours, or at -20°C for more than 48 Hrs.



3.SAFETY



If liquid crystal leak out of a damaged glass cell, DO NOT put it in your mouth or touch eyes, if the liquid crystal touch your skin or clothes, please wash it off immediately using soap and water.



4.LIMITED WARRANTY



Unless otherwise agreed between ADIA and customer, ADIA will replace or repair any of its LCD modules which are found to be functionally defective when inspected in accordance with ADIA LCD acceptance standards (copies available upon request) for a period of one year from date of shipments. Cosmetic/visual defects over specs must be returned to ADIA within 30 days of shipment. Confirmation of such date shall be based on freight documents. The warranty liability of ADIA limited to repair and/or replacement on the terms set forth above. ADIA shall not be responsible for any subsequent or consequential events.



4.1RETURNING LCM UNDER WARRANTY – TERMS AND CONDITIONS



4.1.No warranty can be granted if the precautions stated above have been disregarded. The typical examples of violations are :

- Broken LCD glass.

- Circuit modified in any way, including addition of components.

4.2.Module repairs will be invoiced to the customer upon mutual agreement. Modules must be returned with sufficient description of the failures or defects. Any connectors or cable installed by the customer must be removed completely without damaging the PCB’s eyelet, conductors and terminals.
